Intelligent Temperature Sensor NC50 Series

Product Overview

The NC50 intelligent temperature sensor is an intelligent digital display temperature measurement and control product integrating temperature measurement, display, and output. The product features an all-electronic structure. It adopts a temperature sensor at the front end, and the output signal is converted into a digital signal processable by a microprocessor through a high-precision A/D converter. It can output analog signals and RS485. It is flexible in use, simple in operation, easy to debug, safe and reliable.

Product Applications

It is widely used in hydropower, tap water, petroleum, chemical, machinery and other industries for measuring, displaying and controlling the temperature of media.

Wiring Diagrams

• Current output wiring diagram (two-wire system):

  Red wire (V+), Blue wire (OUT)

• Voltage output wiring diagram:

  Red wire (V+), Yellow wire (OUT)

• RS485 (digital signal) output wiring diagram (four-wire system):

  Red wire (V+), Blue wire (V-), Yellow wire (A), White wire (B) (connected to PC)

Wiring Installation Diagrams

• Disassembly diagram

• Wiring step diagram (Hirschmann with digital display)

Shanghai Zanke NC50 Series

Step 1: Use a flat-blade screwdriver to pry the disassembly hole to make the internal terminal mounting block separate from the upper cover of the Hirschmann plug.

Step 2: Pull out the internal terminal mounting block after it is separated.

Step 3: Pass the selected shielded cable through the threading hole of the upper cover of the Hirschmann plug first. Four mounting terminals are exposed on the upper part of the terminal mounting block. Connect the wires in sequence according to the wiring diagram.

Selection Table

Wholesale Manufacturer of Intelligent Temperature Sensor NC50 Series

Shanghai Zanke is a wholesale manufacturer of the intelligent temperature sensor NC50 series. At this stage, the main products of Shanghai Zanke Company include flow switches, pressure switches, temperature switches, electromagnetic flowmeters, vortex flowmeters, turbine flowmeters, ultrasonic flowmeters, material (liquid) level flowmeters and other instruments. Application industries: petroleum chemical industry, natural gas, machinery, electric power, metallurgy, building materials, food and pharmaceutical manufacturing, agriculture, environmental protection, etc. (Our company can customize instrument specifications according to users' special requirements and on-site working conditions, and provide installation and commissioning services.)
